Contains position and status information about a mouse event. More...

#include <juce_MouseEvent.h>

Collaboration diagram for juce::MouseEvent:

[legend]

Public Member Functions
	MouseEvent (const MouseEvent &)=default

	MouseEvent (MouseEvent &&)=default

	MouseEvent (MouseInputSource source, Point< float > position, ModifierKeys modifiers, float pressure, float orientation, float rotation, float tiltX, float tiltY, Component eventComponent, Component originator, Time eventTime, Point< float > mouseDownPos, Time mouseDownTime, int numberOfClicks, bool mouseWasDragged) noexcept
	Creates a MouseEvent. More...

int	getDistanceFromDragStart () const noexcept
	Returns the straight-line distance between where the mouse is now and where it was the last time the button was pressed. More...

int	getDistanceFromDragStartX () const noexcept
	Returns the difference between the mouse's current x position and where it was when the button was last pressed. More...

int	getDistanceFromDragStartY () const noexcept
	Returns the difference between the mouse's current y position and where it was when the button was last pressed. More...

MouseEvent	getEventRelativeTo (Component *newComponent) const noexcept
	Creates a version of this event that is relative to a different component. More...

int	getLengthOfMousePress () const noexcept
	Returns the time that the mouse button has been held down for. More...

Point< int >	getMouseDownPosition () const noexcept
	Returns the coordinates of the last place that a mouse was pressed. More...

Point< int >	getMouseDownScreenPosition () const
	Returns the coordinates at which the mouse button was last pressed. More...

int	getMouseDownScreenX () const
	Returns the x coordinate at which the mouse button was last pressed. More...

int	getMouseDownScreenY () const
	Returns the y coordinate at which the mouse button was last pressed. More...

int	getMouseDownX () const noexcept
	Returns the x coordinate of the last place that a mouse was pressed. More...

int	getMouseDownY () const noexcept
	Returns the y coordinate of the last place that a mouse was pressed. More...

int	getNumberOfClicks () const noexcept
	For a click event, the number of times the mouse was clicked in succession. More...

Point< int >	getOffsetFromDragStart () const noexcept
	Returns the difference between the mouse's current position and where it was when the button was last pressed. More...

Point< int >	getPosition () const noexcept
	The position of the mouse when the event occurred. More...

Point< int >	getScreenPosition () const
	Returns the mouse position of this event, in global screen coordinates. More...

int	getScreenX () const
	Returns the mouse x position of this event, in global screen coordinates. More...

int	getScreenY () const
	Returns the mouse y position of this event, in global screen coordinates. More...

bool	isOrientationValid () const noexcept
	Returns true if the orientation value for this event is meaningful. More...

bool	isPressureValid () const noexcept
	Returns true if the pressure value for this event is meaningful. More...

bool	isRotationValid () const noexcept
	Returns true if the rotation value for this event is meaningful. More...

bool	isTiltValid (bool tiltX) const noexcept
	Returns true if the current tilt value (either x- or y-axis) is meaningful. More...

bool	mouseWasClicked () const noexcept
	Returns true if the mouse event is part of a click gesture rather than a drag. More...

bool	mouseWasDraggedSinceMouseDown () const noexcept
	Returns true if the user seems to be performing a drag gesture. More...

MouseEvent &	operator= (const MouseEvent &)=delete

MouseEvent &	operator= (MouseEvent &&)=delete

MouseEvent	withNewPosition (Point< float > newPosition) const noexcept
	Creates a copy of this event with a different position. More...

MouseEvent	withNewPosition (Point< int > newPosition) const noexcept
	Creates a copy of this event with a different position. More...

Static Public Member Functions
static int	getDoubleClickTimeout () noexcept
	Returns the application-wide setting for the double-click time limit. More...

static void	setDoubleClickTimeout (int timeOutMilliseconds) noexcept
	Changes the application-wide setting for the double-click time limit. More...

Public Attributes
Component *const	eventComponent
	The component that this event applies to. More...

const Time	eventTime
	The time that this mouse-event occurred. More...

const ModifierKeys	mods
	The key modifiers associated with the event. More...

const Point< float >	mouseDownPosition
	The coordinates of the last place that a mouse button was pressed. More...

const Time	mouseDownTime
	The time that the corresponding mouse-down event occurred. More...

const float	orientation
	The orientation of the touch input for this event in radians where 0 indicates a touch aligned with the x-axis and pointing from left to right; increasing values indicate rotation in the clockwise direction. More...

Component *const	originalComponent
	The component that the event first occurred on. More...

const Point< float >	position
	The position of the mouse when the event occurred. More...

const float	pressure
	The pressure of the touch or stylus for this event. More...

const float	rotation
	The rotation of the pen device for this event in radians. More...

MouseInputSource	source
	The source device that generated this event. More...

const float	tiltX
	The tilt of the pen device along the x-axis between -1.0 and 1.0. More...

const float	tiltY
	The tilt of the pen device along the y-axis between -1.0 and 1.0. More...

const int	x
	The x-position of the mouse when the event occurred. More...

const int	y
	The y-position of the mouse when the event occurred. More...

Private Attributes
const uint8	numberOfClicks

const uint8	wasMovedSinceMouseDown

Detailed Description

Contains position and status information about a mouse event.

See also: MouseListener, Component::mouseMove, Component::mouseEnter, Component::mouseExit, Component::mouseDown, Component::mouseUp, Component::mouseDrag

@tags{GUI}

Constructor & Destructor Documentation

◆ MouseEvent() [1/3]

juce::MouseEvent::MouseEvent	(	MouseInputSource	source,
		Point< float >	position,
		ModifierKeys	modifiers,
		float	pressure,
		float	orientation,
		float	rotation,
		float	tiltX,
		float	tiltY,
		Component *	eventComponent,
		Component *	originator,
		Time	eventTime,
		Point< float >	mouseDownPos,
		Time	mouseDownTime,
		int	numberOfClicks,
		bool	mouseWasDragged
	)

noexcept

Creates a MouseEvent.

Normally an application will never need to use this.

Parameters

source	the source that's invoking the event
position	the position of the mouse, relative to the component that is passed-in
modifiers	the key modifiers at the time of the event
pressure	the pressure of the touch or stylus, in the range 0 to 1. Devices that do not support force information may return 0.0, 1.0, or a negative value, depending on the platform
orientation	the orientation of the touch input for this event in radians. The default is 0
rotation	the rotation of the pen device for this event in radians. The default is 0
tiltX	the tilt of the pen device along the x-axis between -1.0 and 1.0. The default is 0
tiltY	the tilt of the pen device along the y-axis between -1.0 and 1.0. The default is 0
eventComponent	the component that the mouse event applies to
originator	the component that originally received the event
eventTime	the time the event happened
mouseDownPos	the position of the corresponding mouse-down event (relative to the component that is passed-in). If there isn't a corresponding mouse-down (e.g. for a mouse-move), this will just be the same as the current mouse-x position.
mouseDownTime	the time at which the corresponding mouse-down event happened If there isn't a corresponding mouse-down (e.g. for a mouse-move), this will just be the same as the current mouse-event time.
numberOfClicks	how many clicks, e.g. a double-click event will be 2, a triple-click will be 3, etc
mouseWasDragged	whether the mouse has been dragged significantly since the previous mouse-down

◆ MouseEvent() [2/3]

juce::MouseEvent::MouseEvent ( const MouseEvent & )

default

◆ MouseEvent() [3/3]

juce::MouseEvent::MouseEvent ( MouseEvent && )

default

Member Function Documentation

◆ getDistanceFromDragStart()

int juce::MouseEvent::getDistanceFromDragStart ( ) const

noexcept

Returns the straight-line distance between where the mouse is now and where it was the last time the button was pressed.

This is quite handy for things like deciding whether the user has moved far enough for it to be considered a drag operation.

See also: getDistanceFromDragStartX

◆ getDistanceFromDragStartX()

int juce::MouseEvent::getDistanceFromDragStartX ( ) const

noexcept

Returns the difference between the mouse's current x position and where it was when the button was last pressed.

See also: getDistanceFromDragStart

◆ getDistanceFromDragStartY()

int juce::MouseEvent::getDistanceFromDragStartY ( ) const

noexcept

Returns the difference between the mouse's current y position and where it was when the button was last pressed.

See also: getDistanceFromDragStart

◆ getDoubleClickTimeout()

static int juce::MouseEvent::getDoubleClickTimeout ( )

staticnoexcept

Returns the application-wide setting for the double-click time limit.

This is the maximum length of time between mouse-clicks for it to be considered a double-click. It's used by the Component class.

See also: setDoubleClickTimeout, MouseListener::mouseDoubleClick

◆ getEventRelativeTo()

MouseEvent juce::MouseEvent::getEventRelativeTo ( Component * newComponent ) const

noexcept

Creates a version of this event that is relative to a different component.

The x and y positions of the event that is returned will have been adjusted to be relative to the new component. The component pointer that is passed-in must not be null.

◆ getLengthOfMousePress()

int juce::MouseEvent::getLengthOfMousePress ( ) const

noexcept

Returns the time that the mouse button has been held down for.

If called from a mouseDrag or mouseUp callback, this will return the number of milliseconds since the corresponding mouseDown event occurred. If called in other contexts, e.g. a mouseMove, then the returned value may be 0 or an undefined value.

◆ getMouseDownPosition()

Point<int> juce::MouseEvent::getMouseDownPosition ( ) const

noexcept

Returns the coordinates of the last place that a mouse was pressed.

The coordinates are relative to the component specified in MouseEvent::component. For a floating point version of this value, see mouseDownPosition.

See also: mouseDownPosition, getDistanceFromDragStart, getDistanceFromDragStartX, mouseWasDraggedSinceMouseDown

Referenced by juce::LassoComponent< SelectableItemType >::beginLasso().

◆ getMouseDownScreenPosition()

Point<int> juce::MouseEvent::getMouseDownScreenPosition ( ) const

Returns the coordinates at which the mouse button was last pressed.

The coordinates are relative to the top-left of the main monitor.

See also: getScreenPosition

◆ getMouseDownScreenX()

int juce::MouseEvent::getMouseDownScreenX ( ) const

Returns the x coordinate at which the mouse button was last pressed.

The coordinates are relative to the top-left of the main monitor.

See also: getMouseDownScreenPosition

◆ getMouseDownScreenY()

int juce::MouseEvent::getMouseDownScreenY ( ) const

Returns the y coordinate at which the mouse button was last pressed.

The coordinates are relative to the top-left of the main monitor.

See also: getMouseDownScreenPosition

◆ getMouseDownX()

int juce::MouseEvent::getMouseDownX ( ) const

noexcept

Returns the x coordinate of the last place that a mouse was pressed.

The coordinate is relative to the component specified in MouseEvent::component.

See also: getDistanceFromDragStart, getDistanceFromDragStartX, mouseWasDraggedSinceMouseDown

◆ getMouseDownY()

int juce::MouseEvent::getMouseDownY ( ) const

noexcept

Returns the y coordinate of the last place that a mouse was pressed.

The coordinate is relative to the component specified in MouseEvent::component.

See also: getDistanceFromDragStart, getDistanceFromDragStartX, mouseWasDraggedSinceMouseDown

◆ getNumberOfClicks()

int juce::MouseEvent::getNumberOfClicks ( ) const

inlinenoexcept

For a click event, the number of times the mouse was clicked in succession.

So for example a double-click event will return 2, a triple-click 3, etc.

◆ getOffsetFromDragStart()

Point<int> juce::MouseEvent::getOffsetFromDragStart ( ) const

noexcept

Returns the difference between the mouse's current position and where it was when the button was last pressed.

See also: getDistanceFromDragStart

◆ getPosition()

Point<int> juce::MouseEvent::getPosition ( ) const

noexcept

The position of the mouse when the event occurred.

This position is relative to the top-left of the component to which the event applies (as indicated by the MouseEvent::eventComponent field).

For a floating-point position, see MouseEvent::position

Referenced by juce::LassoComponent< SelectableItemType >::dragLasso().

◆ getScreenPosition()

Point<int> juce::MouseEvent::getScreenPosition ( ) const

Returns the mouse position of this event, in global screen coordinates.

The coordinates are relative to the top-left of the main monitor.

See also: getMouseDownScreenPosition

◆ getScreenX()

int juce::MouseEvent::getScreenX ( ) const

Returns the mouse x position of this event, in global screen coordinates.

The coordinates are relative to the top-left of the main monitor.

See also: getScreenPosition

◆ getScreenY()

int juce::MouseEvent::getScreenY ( ) const

Returns the mouse y position of this event, in global screen coordinates.

The coordinates are relative to the top-left of the main monitor.

See also: getScreenPosition

◆ isOrientationValid()

bool juce::MouseEvent::isOrientationValid ( ) const

noexcept

Returns true if the orientation value for this event is meaningful.

◆ isPressureValid()

bool juce::MouseEvent::isPressureValid ( ) const

noexcept

Returns true if the pressure value for this event is meaningful.

◆ isRotationValid()

bool juce::MouseEvent::isRotationValid ( ) const

noexcept

Returns true if the rotation value for this event is meaningful.

◆ isTiltValid()

bool juce::MouseEvent::isTiltValid ( bool tiltX ) const

noexcept

Returns true if the current tilt value (either x- or y-axis) is meaningful.

◆ mouseWasClicked()

bool juce::MouseEvent::mouseWasClicked ( ) const

noexcept

Returns true if the mouse event is part of a click gesture rather than a drag.

This is effectively the opposite of mouseWasDraggedSinceMouseDown()

◆ mouseWasDraggedSinceMouseDown()

bool juce::MouseEvent::mouseWasDraggedSinceMouseDown ( ) const

noexcept

Returns true if the user seems to be performing a drag gesture.

This is only meaningful if called in either a mouseUp() or mouseDrag() method.

It will return true if the user has dragged the mouse more than a few pixels from the place where the mouse-down occurred or the mouse has been held down for a significant amount of time.

Once they have dragged it far enough for this method to return true, it will continue to return true until the mouse-up, even if they move the mouse back to the same location at which the mouse-down happened. This means that it's very handy for objects that can either be clicked on or dragged, as you can use it in the mouseDrag() callback to ignore small movements they might make while trying to click.

◆ operator=() [1/2]

MouseEvent& juce::MouseEvent::operator= ( const MouseEvent & )

delete

◆ operator=() [2/2]

MouseEvent& juce::MouseEvent::operator= ( MouseEvent && )

delete

◆ setDoubleClickTimeout()

static void juce::MouseEvent::setDoubleClickTimeout ( int timeOutMilliseconds )

staticnoexcept

Changes the application-wide setting for the double-click time limit.

This is the maximum length of time between mouse-clicks for it to be considered a double-click. It's used by the Component class.

See also: getDoubleClickTimeout, MouseListener::mouseDoubleClick

◆ withNewPosition() [1/2]

MouseEvent juce::MouseEvent::withNewPosition ( Point< float > newPosition ) const

noexcept

Creates a copy of this event with a different position.

All other members of the event object are the same, but the x and y are replaced with these new values.

◆ withNewPosition() [2/2]

MouseEvent juce::MouseEvent::withNewPosition ( Point< int > newPosition ) const

noexcept

Creates a copy of this event with a different position.

All other members of the event object are the same, but the x and y are replaced with these new values.

Member Data Documentation

◆ eventComponent

Component* const juce::MouseEvent::eventComponent

The component that this event applies to.

This is usually the component that the mouse was over at the time, but for mouse-drag events the mouse could actually be over a different component and the events are still sent to the component that the button was originally pressed on.

The x and y member variables are relative to this component's position.

If you use getEventRelativeTo() to retarget this object to be relative to a different component, this pointer will be updated, but originalComponent remains unchanged.

See also: originalComponent

◆ eventTime

const Time juce::MouseEvent::eventTime

The time that this mouse-event occurred.

◆ mods

const ModifierKeys juce::MouseEvent::mods

The key modifiers associated with the event.

This will let you find out which mouse buttons were down, as well as which modifier keys were held down.

When used for mouse-up events, this will indicate the state of the mouse buttons just before they were released, so that you can tell which button they let go of.

Referenced by juce::LassoComponent< SelectableItemType >::dragLasso().

◆ mouseDownPosition

const Point<float> juce::MouseEvent::mouseDownPosition

The coordinates of the last place that a mouse button was pressed.

The coordinates are relative to the component specified in MouseEvent::component.

See also: getDistanceFromDragStart, getDistanceFromDragStartX, mouseWasDraggedSinceMouseDown

◆ mouseDownTime

const Time juce::MouseEvent::mouseDownTime

The time that the corresponding mouse-down event occurred.

◆ numberOfClicks

const uint8 juce::MouseEvent::numberOfClicks

private

◆ orientation

const float juce::MouseEvent::orientation

The orientation of the touch input for this event in radians where 0 indicates a touch aligned with the x-axis and pointing from left to right; increasing values indicate rotation in the clockwise direction.

The default is 0.

◆ originalComponent

Component* const juce::MouseEvent::originalComponent

The component that the event first occurred on.

If you use getEventRelativeTo() to retarget this object to be relative to a different component, this value remains unchanged to indicate the first component that received it.

See also: eventComponent

◆ position

const Point<float> juce::MouseEvent::position

The position of the mouse when the event occurred.

This value is relative to the top-left of the component to which the event applies (as indicated by the MouseEvent::eventComponent field).

This is a more accurate floating-point version of the position returned by getPosition() and the integer x and y member variables.

◆ pressure

const float juce::MouseEvent::pressure

The pressure of the touch or stylus for this event.

The range is 0 (soft) to 1 (hard). If the input device doesn't provide any pressure data, it may return a negative value here, or 0.0 or 1.0, depending on the platform.

◆ rotation

const float juce::MouseEvent::rotation

The rotation of the pen device for this event in radians.

Indicates the clockwise rotation, or twist, of the pen. The default is 0.

◆ source

MouseInputSource juce::MouseEvent::source

The source device that generated this event.

◆ tiltX

const float juce::MouseEvent::tiltX

The tilt of the pen device along the x-axis between -1.0 and 1.0.

A positive value indicates a tilt to the right. The default is 0.

◆ tiltY

const float juce::MouseEvent::tiltY

The tilt of the pen device along the y-axis between -1.0 and 1.0.

A positive value indicates a tilt toward the user. The default is 0.

◆ wasMovedSinceMouseDown

const uint8 juce::MouseEvent::wasMovedSinceMouseDown

private

◆ x

const int juce::MouseEvent::x

The x-position of the mouse when the event occurred.

This value is relative to the top-left of the component to which the event applies (as indicated by the MouseEvent::eventComponent field).

For a floating-point coordinate, see MouseEvent::position

◆ y

const int juce::MouseEvent::y

The y-position of the mouse when the event occurred.

This value is relative to the top-left of the component to which the event applies (as indicated by the MouseEvent::eventComponent field).

For a floating-point coordinate, see MouseEvent::position

The documentation for this class was generated from the following file:

juce_MouseEvent.h

Public Member Functions

Static Public Member Functions

Public Attributes

Private Attributes

Detailed Description

Constructor & Destructor Documentation

◆ MouseEvent() [1/3]

◆ MouseEvent() [2/3]

◆ MouseEvent() [3/3]

Member Function Documentation

◆ getDistanceFromDragStart()

◆ getDistanceFromDragStartX()

◆ getDistanceFromDragStartY()

◆ getDoubleClickTimeout()

◆ getEventRelativeTo()

◆ getLengthOfMousePress()

◆ getMouseDownPosition()

◆ getMouseDownScreenPosition()

◆ getMouseDownScreenX()

◆ getMouseDownScreenY()

◆ getMouseDownX()

◆ getMouseDownY()

◆ getNumberOfClicks()

◆ getOffsetFromDragStart()

◆ getPosition()

◆ getScreenPosition()

◆ getScreenX()

◆ getScreenY()

◆ isOrientationValid()

◆ isPressureValid()

◆ isRotationValid()

◆ isTiltValid()

◆ mouseWasClicked()

◆ mouseWasDraggedSinceMouseDown()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ setDoubleClickTimeout()

◆ withNewPosition() [1/2]

◆ withNewPosition() [2/2]

Member Data Documentation

◆ eventComponent

◆ eventTime

◆ mods

◆ mouseDownPosition

◆ mouseDownTime

◆ numberOfClicks

◆ orientation

◆ originalComponent

◆ position

◆ pressure

◆ rotation

◆ source

◆ tiltX

◆ tiltY

◆ wasMovedSinceMouseDown

◆ x

◆ y
